Vertical 01 · Irrigation design & engineering consultancy
The engineering, before anything is bought.
For architects, landscape consultants, developers, farm owners and contractors who need irrigation engineered properly — and documented so it can be tendered, built and maintained.
- Design only
- Independent of supply
- Stages 1–6
- Of our nine-stage process
- Tender-ready
- Drawings, BOQ, specifications
- Optional review
- Execution & commissioning witness
When to bring us in
Before the mainline route is fixed and the pump is bought.
Most irrigation problems are designed in — a pump chosen on nominal HP, a filter sized for the wrong water, zones that cannot all run inside the available window.
Consultancy puts the engineering first: water demand, source availability, topography, pressure, hydraulics, operating philosophy and automation — documented as a design set any competent installer can build to.
Who it is for
Engineering that sits inside your project team.
Each engagement is scoped to what the project needs — a villa garden does not need a pump-curve verification report.
Architects & landscape consultants
Irrigation drawings and specifications that sit alongside your landscape package and tender set.
Developers
An independent design basis and BOQ to tender against, plus review of the installer’s work if you want it.
Farms & estates
Crop-based water demand, hydraulics and pump duty for new plantations, or re-engineering an under-performing system.
Contractors
Hydraulic design and detailed engineering for projects you execute yourself.
Deliverables
What a design package contains.
The full set, when the project warrants it. Anonymised samples are available on request.
- ET / ETc, hydrozones, irrigation window
- Design basis & water-demand calculation
- Zoning, valve locations, lateral layout
- Irrigation layout / zone plan
- Flow, velocity, friction loss, residual pressure
- Hydraulic calculation sheets
- Pipe schedules, critical points
- Mainline / sub-main sizing & profile
- Derived from the system, not nominal HP
- Pump duty & curve selection
- Filtration, fertigation, protection
- Head-control / pump-room schematic
- Controllers, valves, sensors, communication
- Automation architecture
- Tender-ready, manufacturer-neutral where required
- BOQ & technical specifications
How consultancy runs
Stages 1 to 6, delivered as a document set.
Data collection → water requirement → zoning → hydraulic engineering → equipment and automation → detailed engineering.
- Site survey where required: source, mainline routes, elevations, pump-room location, constraints
- Design reviews with the consultant team at concept, detailed and tender stages
- Manufacturer-neutral specifications, or specified brands where the project requires them
- Compliance with project, consultant, manufacturer and applicable Indian and international codes
- Optional execution review and commissioning witness
Your next step
Send us the drawings. We’ll tell you what the irrigation needs.
Landscape plans, agronomic plan, water-source details — whatever you have.
